Overview
The SOE+ 5 MW is a modular industrial Solid Oxide Electrolyser System designed for large-scale hydrogen production. Powered by Dynelectro’s proprietary AC:DC architecture, it delivers industry-leading efficiency, ultra-low degradation and dynamic operation in a scalable containerised platform. Enabling industry-leading SOEC stack lifetimes of 7–10 years under industrial operating conditions.
Engineered with precision
Each 1 MW module is designed for seamless integration into existing industrial plants and scalable installation up to multi-MW configurations.
Documented performance
Tested for 25,000 hours at ultra-low degradation rates (<0.05 % per 1,000 h), Dynelectro’s technology delivers proven performance, long-term cost advantages, and a scalable pathway to net-zero industrial operations.
- Low stack degradation – enable 5x SOEC stack lifetime extension due to alternating AC/DC operation – <0.05% stack degradation per 1,000 hours
- Increase H2 output – 50% higher hydrogen output per power unit vs. Alkaline / PEM electrolysis
- Reduced cost – 20% lower LCOH vs. other PtX technologies
- Dynamic operation / Variable Load Following – ideal for fluctuating renewable input
- Ancillary Grid Service offering possible – flexible operation enables availability for FFR / FCR / FRR capacity offering.
Technical Specification:
| ELECTRICAL RATING |
| Max. System power consumption |
0.275 MW |
| Power consumption (stack) |
33.5 kWh/kg (3 kWh/Nm³) |
| Power consumption (system) |
37.8-40 kWh/kg H₂ (3.4-3.6 kWh/Nm³ H₂) |
| System electrical efficiency with heat integration |
≈ 90% (electrical) |
| System electrical efficiency w/o heat integration |
> 70% (electrical) |
| HYDROGEN PRODUCTION |
| Max. Production rate |
Up to 5.4 kg/h (64 Nm³/h) |
| Operational pressure |
0.025 bar(g) |
| Hydrogen purity (dry) |
> 99.9 % |
| Hot start-up time |
<10 minutes |
| Dynamic operation |
5-100% load (idle to full load) |
| Dynamic load change response time |
< 30 sec (5-100%) |
| WASTE HEAT / STEAM INPUT |
| Operational pressure |
4.5-6 bar(g) |
| Temperature |
150-200 °C |
| Consumption |
64 kg/h |
| ADDITIONAL SPECIFICATIONS |
| Ambient temperature |
-20 °C to +40 °C |
| Footprint |
Approx. 3m x 6m (20 ft container) |
| Stack lifetime |
<0.05 % degradation per 1,000 hours |
