Expression of Interest
Expression of interest for our dynamic electrolyser units (DEU)
Expression of interest in our product line available here.
Dynelectro is a Danish solid oxide electrolyser equipment manufacture. We have a proprietary technology which lowers the cost of hydrogen through improving lifetime of the core technology, the stack. The unit is fully dynamic meaning that it is able to load-follow the fluctuating profile of renewable energy such as wind or solar power. With system electrical efficiency above 85%, our dynamic electrolyser unit (DEU) offers proven, scalable and best-in-class levelised cost of hydrogen (LCOH).
Additionally, the unit can operate in reverse, generating electricity, meaning that grid balancing and ancillary services are possible. Electrical efficiency can be further improved by integrating heat from other industrial sources.
We design and manufacture our units using commercially available stacks and hardware. Units start at 40 kW and upward to 1 MW scale with a 12-month delivery from time of ordering. Systems beyond 1 MW are available with 24-month lead time.
Reach us at info@dynelectro.dk to book a site visit to see one of our hydrogen production prototypes in operation.
Project specific inquires here.
| Electrical Rating | ||
| System Power (AC) | 1,092 | kW |
| Power Consumption (stack) | 3 | kWh/Nm3 |
| Power Consumption (AC) | 3.4 – 3.6 | kWh/Nm3 |
| System Electrical Efficiency (AC) | 84-88 | % |
| Hydrogen Production | ||
| Production Rate | 321 | Nm3/h |
| Operational Pressure | 0.025 | barg |
| Operational Temperature | 40 – 215 | °C |
| Maximum Purity (dry basis) | 99.99 | % |
| Hot Start-up Time | < 10 | min |
| Steam Input | ||
| Pressure | 4.5 – 6.0 | barg |
| Temperature | 150 – 200 | °C |
| Consumption | 366 | kg/hr |
| Additional Specifications | ||
| Ambient Temperature | -20 to +40 | °C |
| Footprint | 9 x 21 | m2 |
